Camouflage Monopole Tower
Height 15m-80m, material galvanized steel/aluminum alloy, load-bearing capacity ≥500kg, applicable temperature -40℃~60℃.
Versatile single-pole structure, easy installation, low maintenance.
Features
The camouflage monopole tower is a multi-functional vertical structure consisting of a single solid pole, designed for supporting communication antennas, monitoring equipment, and lighting fixtures. The camouflage monopole tower features a compact design with a small footprint, making it ideal for urban areas, industrial parks, and remote regions with limited space. It undergoes strict quality inspections, including load-bearing and anti-corrosion tests, to meet ISO9001:2015 and national safety standards, providing reliable support for diverse outdoor equipment.
Product Parameters
|
Technical Indicators |
Specification Parameters |
|
Height Range |
15m-80m |
|
Material |
Galvanized Steel/Aluminum Alloy |
|
Load-Bearing Capacity |
≥500kg |
|
Diameter Range |
300mm-800mm |
|
Operating Temperature |
-40℃~60℃ |
|
Wind Resistance |
≤35m/s |
|
Anti-Corrosion Treatment |
Hot-dip galvanizing/Powder coating |
|
Service Life |
25 years (steel)/20 years (aluminum) |
Product Features
Versatile Applications
Compatible with communication antennas, CCTV cameras, and street lamps, supporting multi-equipment integration.
Lightweight & Durable
Aluminum alloy variants weigh 40% less than steel towers, while galvanized steel ensures 25-year service life.
Easy Installation
Modular design allows assembly by 4-6 workers in 1-2 days.
Weather Resistant
Withstands extreme temperatures (-40℃~60℃) and 12-level winds (35m/s), adapting to harsh environments.
Components
Tower Pole: Galvanized steel pipe or aluminum alloy tube.
Mounting Brackets: Adjustable angle brackets for equipment installation (load-bearing ≥500kg).
Accessories: Climbing rungs, safety railings, and lightning protection systems.
Base: Precast concrete base or ground anchor fixation for different installation scenarios.
Main Applications
Communication Networks: Supporting 4G/5G base station antennas in urban and rural areas.
Security Monitoring: Mounting CCTV cameras for road traffic, industrial parks, and public security surveillance.
Outdoor Lighting: Installing high-power street lamps for highways, ports, and construction sites.
Environmental Monitoring: Supporting wind speed, temperature, and air quality detection equipment.
Why Choose Us
Factory Direct Pricing
Eliminates intermediaries, offering 15-20% lower prices than distributors.
Lifecycle Cost
Minimal maintenance and long service life reduce total cost of ownership by 40%.
Customization Cost-Efficiency
Modular production reduces customization costs by 30% compared to traditional towers.
FAQ
Q: What is the maximum number of antennas it can support?
A: A 50m steel camouflage monopole tower can support up to 8 communication antennas (each ≤50kg) with proper spacing.
Q: Can it be installed on rooftops?
A: Yes, we offer lightweight rooftop models (weight ≤1.5 tons) with reinforced base plates to avoid building structure damage.
Q: How to transport the tower?
A: Segmental design allows transportation via standard trucks, reducing logistics costs by 25% compared to integrated towers.
